Products > Filter Belt > Press Filter Belt > Press Filter Belt
Product name : Press Filter Belt
Product No. : 2015610111234
←[Previous Product]
Online Inquiry         Email Us

  Details:


STANDARD

SPECIFICATION FOR  PT885B Style Belt



Raw Material:





Warp Yarn(mm)

PET Mono 0.66



Weft Yarn(mm)

PET Mono 1.0















Warp Threads Thickness

Weft Threads Thickness

Area Weight(克重)

185

59

1670

Threads/10cm

Threads/10cm

g/m2



Thickness(厚度)

2.17

mm



Mean Air Permeability(透气量)

1900-2050

L/m2/S@200 pa



Breaking Strength-Warp(径向强力)

23500

N / 5cm



Breaking Elongation( N/5cm)-Warp(径向断裂伸长率)

25

%













Main application of such belt: The craft filtration of large-scale industrial production: supporting to different kinds of filter, then be widely applied in tailings, coal washing, paper cleaning grouting, alumina, phosphate, potash, juice press, medicine, filtering, drying sterilization of food, citric acid, filters, cornstarch, vegetable oil production, sludge drying and filtration industries.

PS: The Air Permeability and the Threads Thickness can be adjusted depend on the customers’ requirements.
